Basic class for the hydraulic interface element plugin object. More...

#include <gmpThermoInterface.h>

Inheritance diagram for GmpThermoInterface:

[legend]

Collaboration diagram for GmpThermoInterface:

[legend]

Public Types
enum	InterfacePropertyIds { IOPEN_ID = GmpThermoFemPhysics::NUM_PROPER_IDS , Kti_ID , Htc_ID , NUM_PROPER_IDS }
	IDs for physics element properties. More...

Public Types inherited from GmpThermoFemPhysics
enum	PhysicsAttributeIds { ISOPARAMETRIC_ID , HAS_ELEMENT_GENERATION_ID , HF_MODE_ID , HF_DIRECT_ID }
	IDs for physics attributes. More...

enum	StateVarIds { T_ID }
	IDs fo physics state vars. More...

enum	NodeAttributeIds { Q_NA_ID }
	IDs for physics node attributes. More...

enum	GaussAttributeIds { Q_GA_ID }
	IDs for physics Gauss attributes. More...

enum	ElementPropertyIds { K_ID , THICKNESS_ID , G_ID , RHO_ID , CP_ID , NUM_PROPER_IDS }
	IDs for physics element properties. More...

enum	BoundaryConditionIds { FIXED_T_BC_ID , FIXED_HF_BC_ID , CONVECTIVE_BC_ID , POINT_GENERATION_BC_ID }
	IDs for accepted boundary condition types. More...

enum	BoundaryConditionValueIds { BC_T_ID , BC_Q_ID , BC_QDIR_ID , BC_H_ID , BC_TA_ID , BC_G_ID , BC_POS_ID }
	IDs for property values from accepted boundary condition types. More...

Public Types inherited from GmpFemPhysicsCommon
enum	DiscSetRequiredMode

enum	DerivedResultsRecoveryMode

typedef TList< Attribute >	AttributeList

typedef TList< Value >	ValueList

Public Types inherited from GmpFemPhysics
enum	FemResultType

enum	FemSupportedParallelMethods

Public Member Functions
	GmpThermoInterface (const char pluginType, GmSimulationData simulation, QString id, QString description, const GmLogCategory &logger)

virtual	~GmpThermoInterface ()
	Destructor.

virtual const QVariantMap *	physicsMetaDataMap ()
	Returns a reference for the hydraulic interface attribute map, built when the function is called for the first time.

virtual bool	checkAndLoadAttributeAccessors (LuaTable &nodeTable, LuaTable &cellTable, LuaTable &gaussTable)
	Reimplementation of the common function to set initial gauss attributes.

virtual bool	beforeElementStiffnessLoop (const GmpFemMatrixSet &elemMatrices, const GmpFemVectorSet &elemVectors)

virtual GmpFemPhysics::FemResultType	fillElementData (const GmElement *e, GmpFemMatrixSet &elemMatrices, GmpFemVectorSet &elemVectors)
	Fills the element matrices and vectors for a generic Interface element.

virtual bool	calcDerivedResults (bool nonLinearSolver)
	Calc velocity and flow on nodes and/or Gauss points.

virtual bool	addStateItemsToGroup (GmStateDump *state, bool fixedHint, int groupId)

virtual void	fillStorageCompMatrix (const GmElement e, const GmVector coord, int ip, GmMatrix &Sc, const GmVector &N, double c)
	Calculates the compressibility matrix inside the fracture.

virtual void	fillFlowMatrix (const GmElement *e, GmMatrix &Kc, const GmMatrix Bp, const GmVector flowParam, const GmVector N, double c)
	Calculates the flow stiffness matrix according to ....

virtual bool	setInitialConditions () const
	sets the initial value of hydraulic gauss attributes.

virtual double	fillBtMatrix (const GmShape *shape, const GmVector &ncoord, const GmMatrix &X, const GmVector &N, const GmMatrix &J, GmMatrix &Bt)=0
	Given a point 'ncoord', the element coordinate matrix 'X', the point shape functions 'N' and the transformation Jacobian 'J', fills the matrix with cartesian partial derivatives Bt using the provided shape function and returns the scaled jacobian determinant.

virtual void	fillElementTemperature (const GmElement *e, GmVector &pe)
	Given an element, fills the vector pe with nodal Temperature.

virtual double	initiallyOpenElem (const GmElement e, const GmVector coord, int ip) const
	Returns the initially open element

virtual bool	fillThermalConductivityParameters (const GmElement e, GmVector &flowParam, const GmVector coord, int i)
	Returns the thermal conductivity parameters: [kl, Ckt, Ckb].

virtual double	heatTransferCoeficient (const GmElement e, const GmVector coord, int ip) const
	Returns the heat trasnfer coefficient at the top.

virtual double	fractureHeatConductivity (const GmElement e, const GmVector coord, int ip) const
	Returns the longitudinal fracture conductivity.

Public Member Functions inherited from GmpThermoFemPhysics
	GmpThermoFemPhysics (const char pluginType, GmSimulationData simulation, QString id, QString description, const GmLogCategory &logger)
	Constructor. Will be called by the plugin loading code.

virtual	~GmpThermoFemPhysics ()
	Destructor.

virtual const char *	pluginName () const

virtual const char *	pluginType () const

virtual FemResultType	fillElementDataForBc (const GmElement e, const GmBoundaryCondition bc, int bcIndex, int bcListIndex, int border, GmpFemMatrixSet &elemMatrices, GmpFemVectorSet &elemVectors)
	Fills the element stiffness matrix elemK and/or the force vector elemF for element 'e', taking into account convective heat transfer, fixed heat flux and/or point generation boundary conditions, as indicated by the bc parameter.

virtual bool	fixedNodalDofsBc (QVector< int > &nodes, QVector< int > &dof, QVector< double > &values, bool *constantValues) const
	See comments on base class. Fills vectors with prescribed node temperatures.

virtual bool	supportsStateDumping ()
	Tell the world that the temperature physics supports state dumping.

void	fillConductivityMatrix (GmMatrix &K, const GmElement e, const GmVector ip, int ipIndex)
	Fills the conductivity matrix _kMat evaluating accessor at the integration point ip of element e (ncoord can be NULL if accessors do not accept user functions), taking in consideration that the accessor might return scalars or vectors.

Public Member Functions inherited from GmpFemPhysicsCommon
	GmpFemPhysicsCommon (GmSimulationData simulation, QString id, QString description, const GmpFemPhysicsCommonMaterialFactory matFactory, const GmLogCategory &logger)

void	printParameters (const GmLogCategory &logger)

const QVariant &	attribute (int id) const

GmValueAccessor *	nodeAc () const

int	nodeDim () const

bool	isoParametric () const

int	svCount () const

GmValueAccessor *	svAc (int id) const

int	baseDof (int id) const

GmCellAccessor *	propertyAc (int id) const

bool	constantProperty (int id) const

GmValueAccessor *	nodeAttrAc (int id) const

GmCellAccessor *	cellAttrAc (int id) const

GmGaussAccessor *	gaussAttrAc (int id) const

const GmBoundaryCondition *	boundaryCondition (int id) const

const GmContactBoundaryCondition *	contactCondition (int id) const

GmBoundaryConditionAccessor *	bcAc (int id) const

GmContactBoundaryConditionAccessor *	contactAc (int id) const

bool	constantBc (int id) const

bool	constantContactBc (int id) const

const QVector< const GmBoundaryCondition * > &	calcBoundaryConditions () const

GmValueAccessor *	loadAc (int loadId) const

GmDiscontinuityAccessor *	discontinuityAc (int discId) const

GmSegmentCell2DIntersectionCoordAccessor *	discontinuity2dIntersectionCoordAc () const

GmValueAccessor *	cloneSvAcWithDifferentUnit (int id, QString unitSystemName, QString defUnit) const

GmCellAccessor *	clonePropertyAcWithDifferentUnit (int id, QString unitSystemName, QString defUnit) const

GmValueAccessor *	cloneNodeAttrAcWithDifferentUnit (int id, QString unitSystemName, QString defUnit) const

GmCellAccessor *	cloneCellAttrAcWithDifferentUnit (int id, QString unitSystemName, QString defUnit) const

GmGaussAccessor *	cloneGaussAttrAcWithDifferentUnit (int id, QString unitSystemName, QString defUnit) const

const GmpFemPhysicsCommonMaterial *	material (const GmElement *e) const

const QVector< GmpFemPhysicsCommonMaterial * > &	materialList () const

bool	calcDerivedResult (int recoveryMode, GmValueAccessor nodeAc, GmGaussAccessor gaussAc, int resultId=-1)

void	fillElementNodeValues (const GmValueAccessor ac, const GmElement e, GmVector &v, int nv=-1) const

bool	fillMissingNodeValues (GmValueAccessor *ac)

bool	fillScalarFixedNodalBcLists (int bcId, int propertyId, int dofId, QVector< int > &nodes, QVector< int > &dof, QVector< double > &values, bool *constantValues) const

bool	fillVectorFixedNodalBcLists (int bcId, int propertyId, int dofId, bool ignoreZeroValues, bool ignoreDefValues, QVector< int > &nodes, QVector< int > &dof, QVector< double > &values, bool *constantValues) const

bool	fillMultiScalarFixedNodalBcLists (int bcId, const QVector< int > &propertyIds, int dofId, bool ignoreZeroValues, bool ignoreDefValues, QVector< int > &nodes, QVector< int > &dof, QVector< double > &values, bool *constantValues) const

virtual bool	checkLoadedData ()

void	addMaterialTranslation (const char modelName, const char physicsName, int modelIndex, bool defaultMaterial)

GmpFemPhysicsCommonMaterial *	material (QString modelName) const

Public Member Functions inherited from GmpFemPhysics
	GmpFemPhysics (GmSimulationData *simulation, QString id, QString description, const GmLogCategory &logger)

GmElementMesh *	mesh () const

const GmCellGroupSet *	meshGroupSet () const

int	numSupportedExternalLoads () const

const GmCellGroupSet *	externalLoadGroupSet (int loadId) const

const QMap< QString, const GmBoundaryCondition * > &	boundaryConditions () const

GmDiscontinuitySet *	discontinuitySet () const

virtual bool	checkPhysicsDependencies (const QVector< GmpFemPhysics * > &physicsList, int index)

virtual bool	dofByElement (bool fixed=NULL, bool addOnly=NULL, bool *trackChanges=NULL) const

virtual const GmElementDof *	dofMapping (const GmElement *e) const

virtual void	afterElementStiffnessLoop ()

virtual bool	fixedNodalForcesBc (QVector< int > &nodes, QVector< int > &dof, QVector< double > &values) const

virtual FemResultType	fillContactData (const GmContactBoundaryCondition *cbc, int bcIndex1, int bcIndex2, GmMatrixDof &dofMap, GmpFemMatrixSet &matrixSet, GmpFemVectorSet &vecSet)

virtual FemResultType	fillElementDataForLoads (const GmElement *e, int loadId, GmpFemVectorSet &elemVectors)

virtual bool	fillStateControlMapData (QVariantMap *map)

virtual bool	stateControlMapDataLoaded (QVariantMap *map)

virtual bool	stateAboutToBeSaved (GmStateDump *state)

virtual bool	stateSaved (GmStateDump *state)

virtual bool	stateAboutToBeLoaded (GmStateDump *state)

virtual bool	stateLoaded (GmStateDump *state)

virtual QList< int >	changedElements () const

virtual void	clearChangedElements ()

const GmIntegrationRule *	elementIntegrationRule (GmCellType type) const

const GmBorderIntegrationRule *	borderIntegrationRule (GmCellType type, int borderIndex) const

const GmBorderIntegrationRule *	faceIntegrationRule (GmCellType type, int faceIndex) const

const GmBorderIntegrationRule *	edgeIntegrationRule (GmCellType type) const

int	integrationRuleSet () const

bool	setIntegrationRuleSet (int ruleSet)

virtual bool	loadPrivateData (LuaTable &table)

Protected Member Functions
virtual const GmElementDof *	dofMapping (GmCellType type) const

void	fillMiddleCoordinates (const GmElement *e, GmMatrix Xnode, GmMatrix &MX)
	Computes the coordinate at the middle plane of the interface element . Given an element 'e' and the nodal coordinates 'Xnode', fills and returns the matrix with coordinates at the middle plane 'MX'.

Protected Member Functions inherited from GmpThermoFemPhysics
virtual void	calcElementDerivedResultAtPoints (const GmElement *e, int resultId, const GmMatrix &evalPoints, bool evalAtIp, GmMatrix &result)
	The virtual function used by calcDerivedResults() to effectivelly calculate the heat flux at the given evaluation points.

virtual bool	isAxisymmetric ()
	Returns TRUE only for axisymmetric models.

virtual double	axisymmetricFactor (const GmElement *e, const GmMatrix &X, const GmVector &N) const =0
	Returns the factor that should be applied when using axis symetric elements. 1.0 for other etypes.

Protected Member Functions inherited from GmpFemPhysicsCommon
virtual bool	supportsCellType (GmCellType type) const

virtual bool	supportsParallel (FemSupportedParallelMethods methodType) const

virtual Unit	dofUnit (int dof) const

virtual Unit	timeUnit () const

virtual GmVector	timeSim () const

virtual const QList< QPair< int, GmValueAccessor * > > &	dofForceAttributes () const

virtual const QStringList &	supportedBcTypes () const

virtual const QStringList &	supportedContactBcTypes () const

virtual bool	bcAffectsCalc (const GmBoundaryCondition *bc) const

virtual const QStringList &	supportedExternalLoads () const

virtual bool	checkAndLoadPrivateData (LuaTable &table)

virtual bool	checkMeshDimension (int ndim)

virtual bool	checkAndLoadDofMapping (LuaTable &table)

virtual bool	checkAndLoadPropertyAccessors (LuaTable &table)

virtual bool	checkAndLoadExternalLoadAccessors (LuaTable &loadsTable)

virtual bool	checkAndLoadBcAccessors ()

virtual bool	checkAndLoadContactBcAccessors ()

virtual bool	checkAndLoadDiscontinuitySetAccessors (LuaTable &table)

QString	accessorNameList (const QVector< T * > list) const

bool	checkAndLoadPropertyAccessorsAux (LuaTable &table, const QList< Value > &defList, QVector< GmCellAccessor * > &accessors, QVector< bool > &constants)

bool	checkAndLoadBcAccessorsAux (QString attrName, QString msgPrefix, QMap< QString, const T * > &bcMap, QVector< const T * > &boundaryConditions, QVector< Ac * > &bcAccessors, QVector< bool > &constantBcValues, QStringList &boundaryConditionTypes, QVector< const T * > calcBoundaryConditions, Ac (GmPhysics::acGetFn)(const T , QString, QString, Unit, bool, int, int, int, bool, bool))

bool	checkAndLoadNodeAttributeAccessors (LuaTable &table, const QList< Value > &naList, QVector< GmValueAccessor * > &accessors, GmpFemPhysicsCommonMaterial *m=NULL)

bool	checkAndLoadCellAttributeAccessors (LuaTable &table, const QList< Value > &caList, QVector< GmCellAccessor * > &accessors, GmpFemPhysicsCommonMaterial *m=NULL)

bool	checkAndLoadGaussAttributeAccessors (LuaTable &table, const QList< Value > &gaList, QVector< GmGaussAccessor * > &accessors, GmpFemPhysicsCommonMaterial *m=NULL)

bool	checkAndLoadSavedGaussAttributes (const QList< int > &attrIdList, QString prefix, int numGaussAttributes, QVector< int > &savedIdList)

bool	createMaterials (LuaTable &table)

bool	loadAttributes (LuaTable &table)

void	loadUnitSystemData (LuaTable &table)

QString	getUnit (QString id, QString defUnit) const

bool	loadAdditionalPrivateData (LuaTable &table, GmpFemPhysicsData &elemData)

bool	loadNodeData (LuaTable &table, GmpFemPhysicsData &elemData)

bool	loadElementData (LuaTable &table, GmpFemPhysicsData &elemData)

bool	loadNeuralNetworkData (LuaTable &table, const char name, GmpFemNeuralNetwork netData)

Protected Member Functions inherited from GmpFemPhysics
GmGaussAccessor *	gaussAttributeAccessor (GmElementMesh *mesh, QString stdAttributeName, QString msgDescription, LuaTable &table, Unit desiredUnit, bool required, int type=-1, int nlin=-1, int ncol=-1, int history=-1, bool canBeFunction=true, bool create=false, QString createFormat="", int createHistory=-1, bool ignoreWarnings=false)

virtual GmGaussAccessor *	createGaussAttributeAccessor (GmElementMesh *mesh, QString id, int snum, bool locked, Unit desiredUnit, const GmLogCategory &logger) const

Additional Inherited Members
Static Public Member Functions inherited from GmpFemPhysicsCommon
static T	listFromVariant (const QVariant &v)

static void	fillMatrixFromPropertyAc (GmCellAccessor ac, const GmElement e, const GmVector *coord, int ip, GmMatrix &K)

Public Attributes inherited from GmpFemPhysicsCommon
	DS_IGNORED

	DS_REQUIRED

	DS_OPTIONAL

	RECOVER_AT_GAUSS

	RECOVER_AT_NODES

	DIRECT_NODE_EVAL

	ADD_RESULTS

	IP_ONLY

	GAUSS_FILLED

Public Attributes inherited from GmpFemPhysics
	FEM_RESULT_OK

	FEM_ERROR_FI

	FEM_ERROR

	FEM_PARALLEL_FILL_ELEMENT_DATA

	FEM_PARALLEL_FILL_ELEMENT_DATA_BC

	FEM_PARALLEL_FILL_ELEMENT_DATA_EXT_LOADS

	FEM_PARALLEL_FILL_CONTACT_DATA

Protected Attributes inherited from GmpFemPhysicsCommon
GmElementDof *	_dofMap [GM_NUM_CELL_TYPES]

unsigned int	_parallelMethods

Protected Attributes inherited from GmpFemPhysics
GmElementMesh *	_mesh

const GmCellGroupSet *	_gs

int	_intRuleSet

GmDiscontinuitySet *	_discSet

QMap< QString, const GmBoundaryCondition * >	_bcMap

QMap< QString, const GmContactBoundaryCondition * >	_cbcMap

QVector< const GmCellGroupSet * >	_externalLoadGroupSets

Detailed Description

Basic class for the hydraulic interface element plugin object.

This physics plugin calculates temperature inside the fracture

Member Enumeration Documentation

◆ InterfacePropertyIds

enum GmpThermoInterface::InterfacePropertyIds

IDs for physics element properties.

Enumerator
IOPEN_ID	Id for retrieving the initially open element accessor.
Kti_ID	Id for retrieving the longitudinal thermal conductivity tensor accessor.
NUM_PROPER_IDS	The number of property ids above.

Member Function Documentation

◆ addStateItemsToGroup()

bool GmpThermoInterface::addStateItemsToGroup	(	GmStateDump *	state,
		bool	fixedHint,
		int	groupId )

virtual

Reimplemented from GmpFemPhysics.

◆ beforeElementStiffnessLoop()

bool GmpThermoInterface::beforeElementStiffnessLoop	(	const GmpFemMatrixSet &	elemMatrices,
		const GmpFemVectorSet &	elemVectors )

virtual

Reimplemented from GmpThermoFemPhysics.

◆ calcDerivedResults()

bool GmpThermoInterface::calcDerivedResults ( bool nonLinearSolver )

virtual

Calc velocity and flow on nodes and/or Gauss points.

Reimplemented from GmpThermoFemPhysics.

◆ checkAndLoadAttributeAccessors()

bool GmpThermoInterface::checkAndLoadAttributeAccessors	(	LuaTable &	nodeTable,
		LuaTable &	cellTable,
		LuaTable &	gaussTable )

virtual

Reimplementation of the common function to set initial gauss attributes.

Reimplemented from GmpFemPhysicsCommon.

◆ dofMapping()

const GmElementDof * GmpThermoInterface::dofMapping ( GmCellType type ) const

protectedvirtual

Reimplemented from GmpFemPhysicsCommon.

◆ fillElementData()

GmpFemPhysics::FemResultType GmpThermoInterface::fillElementData	(	const GmElement *	e,
		GmpFemMatrixSet &	elemMatrices,
		GmpFemVectorSet &	elemVectors )

virtual

Fills the element matrices and vectors for a generic Interface element.

Reimplemented from GmpThermoFemPhysics.

◆ fillElementTemperature()

void GmpThermoInterface::fillElementTemperature	(	const GmElement *	e,
		GmVector &	pe )

virtual

Given an element, fills the vector pe with nodal Temperature.

Given an element, fills the vector pe with nodal temperature. The vector should have size equal to the number of calculated nodes.

◆ fillFlowMatrix()

void GmpThermoInterface::fillFlowMatrix	(	const GmElement *	e,
		GmMatrix &	Kc,
		const GmMatrix	dNp,
		const GmVector	flowParam,
		const GmVector	Np,
		double	c )

virtual

Calculates the flow stiffness matrix according to ....

Calculates the flow stiffness matrix due to permeability contribution or permeability matrix for element 'e' at the given integration point (coord, ip) storing the result at the Kc matrix. Bp is the strain pore pressure matrix and c a constant equal to w * h * detJ.

This function can operate either in an iso parametric setting (Kc = n x n) or in a super parametric setting (Kc = nf x nf) where n is the number of element nodes and nf the number of element corner nodes.

Returns Kc = Bp.t() * Kaux * Bp * c, where c should be equal to w * h * detJ

◆ fillMiddleCoordinates()

void GmpThermoInterface::fillMiddleCoordinates	(	const GmElement *	e,
		GmMatrix	Xnode,
		GmMatrix &	MX )

protected

Computes the coordinate at the middle plane of the interface element . Given an element 'e' and the nodal coordinates 'Xnode', fills and returns the matrix with coordinates at the middle plane 'MX'.

See comments on base class. Fills matrix with middle coordinates.

◆ fillStorageCompMatrix()

void GmpThermoInterface::fillStorageCompMatrix	(	const GmElement *	e,
		const GmVector *	coord,
		int	ip,
		GmMatrix &	Sc,
		const GmVector &	Np,
		double	c )

virtual

Calculates the compressibility matrix inside the fracture.

Calculates the matrix of thermal "storage / compressibility" for the interface element storing the result at the Sc matrix.
N is the shape function vector and c = w * h * detJ.

This function can operate either in an iso parametric setting (Sc = n x n) or in a super parametric setting (Sc = nf x nf) where n is the number of element corner nodes at middle point.

Returns Sc = N * (rhoF*CpF) * N.t() * c

◆ fillThermalConductivityParameters()

bool GmpThermoInterface::fillThermalConductivityParameters	(	const GmElement *	e,
		GmVector &	flowParam,
		const GmVector *	coord,
		int	i )

virtual

Returns the thermal conductivity parameters: [kl, Ckt, Ckb].

Fills the hydraulic conductivity for longitudinal and normal fluid flow. The longitudinal conductivity is computed according to cubic's law. Returns flowParam = [kl, Lkt, Lkb].

◆ physicsMetaDataMap()

const QVariantMap * GmpThermoInterface::physicsMetaDataMap ( )

virtual

Returns a reference for the hydraulic interface attribute map, built when the function is called for the first time.

Reimplemented from GmpThermoFemPhysics.

◆ setInitialConditions()

bool GmpThermoInterface::setInitialConditions ( ) const

virtual

sets the initial value of hydraulic gauss attributes.

Sets the initial conditions required by interface elements. An = normal aperture.

Returns true

The documentation for this class was generated from the following files:

inc/gmpThermoInterface.h
src/gmpThermoInterface.cpp
