#include <gmpMmMeshMapping.h>

Inheritance diagram for GmpMmMeshMapping:

[legend]

Collaboration diagram for GmpMmMeshMapping:

[legend]

Public Member Functions
	GmpMmMeshMapping (GmSimulationData simData, GmMesh dstMesh, GmSpatialIndex spatialIndex, const GmDiscontinuitySet ds, const QStringList &nodeValues, const QStringList &gaussValues, const QVector< bool > &dstGauss, const QMap< QString, QString > &dstTranslationMap, const GmLogCategory &logger, const QVariantMap &options=QVariantMap())
	Mesh mapping constructor.

virtual	~GmpMmMeshMapping ()
	Virtual destructor.

bool	generate ()
	Process the mesh mapping.

Protected Member Functions
void	getNoDataValues (QVector< GmVector > &values, int dataSize)
	Get no data values.

void	getNodeValues (int srcNodeId, QString valueId, QVector< GmVector > &values)
	Get values from another point.

void	getOutOfMeshValues (const GmVector &crd, QString valueId, QVector< GmVector > &values)
	Get values when point is out of cell mesh.

Protected Attributes
GmElementMesh *	_srcElementMesh

GmValueAccessor *	_srcCrdAcc

GmSpatialIndex *	_spatialIndex

const GmDiscontinuitySet *	_ds

int	_nstates

GmInterpolatorType	_interpType

QVariant	_interpParam

QMap< QString, QVector< const GmValueAccessor * > >	_srcNodeAccMap

QMap< QString, QVector< const GmGaussAccessor * > >	_srcGaussAccMap

Private Member Functions
void	setDstGaussValues ()
	Map values on elements gauss points.

void	setDstNodesValues ()
	Map values on mesh nodes.

virtual bool	acceptSrcGaussValues () const =0
	Returns true if the mapping accepts to transfer gauss values in the source meshe.

virtual bool	checkConsistency ()
	Process the mesh mapping.

virtual void	insertSrcNodeInterp (QString valueId, QVector< const GmValueAccessor * > nodeAccList)

virtual void	insertSrcGaussInterp (QString valueId, QVector< const GmGaussAccessor * > gaussAccList)

virtual void	getValuesFromBI (const GmVector &crd, QString valueId, QVector< GmVector > &values)
	Get values from bucket index.

Private Attributes
QStringList	_srcNodeValues

QStringList	_srcGaussValues

QStringList	_dstNodeValues

QStringList	_dstGaussValues

GmSimulationData *	_simData

GmMesh *	_srcMesh

GmMesh *	_dstMesh

GmElementMesh *	_dstElementMesh

GmValueAccessor *	_dstCrdAcc

QMap< QString, QVector< GmValueAccessor * > >	_dstNodeAccMap

QMap< QString, QVector< GmGaussAccessor * > >	_dstGaussAccMap

QMap< QString, QString >	_dstTranslationMap

bool	_noDataMode

double	_noDataValue

double	_noDataEps

double	_tol

int	_state

bool	_activeOnly

bool	_info

int	_nworkers

int	_ntasks

const GmLogCategory &	_logger
	The logger object used to report errors.

Detailed Description

Class GmpMmMeshMapping.

Constructor & Destructor Documentation

◆ GmpMmMeshMapping()

GmpMmMeshMapping::GmpMmMeshMapping	(	GmSimulationData *	simData,
		GmMesh *	dstMesh,
		GmSpatialIndex *	spatialIndex,
		const GmDiscontinuitySet *	ds,
		const QStringList &	nodeValues,
		const QStringList &	gaussValues,
		const QVector< bool > &	dstGauss,
		const QMap< QString, QString > &	dstTranslationMap,
		const GmLogCategory &	logger,
		const QVariantMap &	options = QVariantMap() )

Mesh mapping constructor.

Parameters

simData	The simulation data object. Needed for access to the task manager (parallelization)
dstMesh	The destination mesh.
spatialIndex	The source spatial index.
nodeValues	A list with the names of node values of source mesh that will be mapped on destination mesh.
gaussValues	A list with the names of gauss attributes of source mesh that will be mapped on destination mesh.
dstGauss	A list of booleans which size is equal to the sum of sizes of nodeValues and gaussValues lists. If boolean is false, it means that the corresponding value will be mapped on the nodes of the destination mesh. If boolean is true, the corresponding value will be mapped on the gauss points of the destination mesh.
dstTranslationMap	A map keyed by the src attribute id, containing am optional alternate name for the destination attribute id.
logger	Plugin logger object used to emmit messages.
options	A set of mapping options. Available options are: 'noDataMode' – Activate the noData mode. Default = false 'noDataValue' – If noDataMode is true, define the noData value. Default = 0.0 'noDataEps' – If noDataMode is true, define the tolerency value on the source mesh frontier. Default = 0.0 'state' – The state number we want to map. Default = -1 (all states will be mapped) 'interpType' – The interpolator type used to compute the data inside a cell. Default = GM_DEFAULT_INTERPOLATOR 'interpParam' – The parameters associated to the interpolator. 'activeOnly' – Should we map data only on the active cells of the destination mesh? No effect if the mapping is done on destination nodes. Default = true 'info' – Print informations about the mesh mapping. Default = false When filling this table, keep in mind that only options different from the default are needed. When an option is not present in the table its default value will be used.

Member Function Documentation

◆ acceptSrcGaussValues()

virtual bool GmpMmMeshMapping::acceptSrcGaussValues ( ) const

privatepure virtual

Returns true if the mapping accepts to transfer gauss values in the source meshe.

Implemented in GmpMmCellMeshMapping, GmpMmElementMeshMapping, and GmpMmNodeMeshMapping.

◆ getValuesFromBI()

void GmpMmMeshMapping::getValuesFromBI	(	const GmVector &	crd,
		QString	valueId,
		QVector< GmVector > &	values )

privatevirtual

Get values from bucket index.

Reimplemented in GmpMmCellMeshMapping, and GmpMmElementMeshMapping.

◆ setDstGaussValues()

void GmpMmMeshMapping::setDstGaussValues ( )

private

Map values on elements gauss points.

Function Object class for parallelizing the work done per mesh cell

The function that will be called for each parallel task

◆ setDstNodesValues()

void GmpMmMeshMapping::setDstNodesValues ( )

private

Map values on mesh nodes.

Function Object class for parallelizing the work done per mesh node

The function that will be called for each parallel task

The documentation for this class was generated from the following files:

inc/gmpMmMeshMapping.h
src/gmpMmMeshMapping.cpp
