A class implementing the GmResultDataSrcInfo interface, storing the metadata and id for a result data registered attribute. It also stores the requested unit and the converter when needed. It is built with the result rule definition only (name + unit) and later completed with the data src definition (info + id) More...
#include <gmResultDataSrc.h>
Public Member Functions | |
| GmAttributeResultDataSrc (int trackId, GmResultDataSrcType type, QString name, Unit unit) | |
| bool | setInfo (const GmAttributeResultDataSrcInfo *info, int id) |
| Sets the associated info object + its id on GmResultsData. If the src data unit is incompatible with the requested unit, returns false. | |
| virtual int | trackId () const |
| Returns a numeric id for this data src (a value between 0 and the number of monitored data srcs in the model, or -1 if this data src is not monitored) | |
| virtual GmResultDataSrcType | type () const |
| Returns the data src type. | |
| virtual QString | alias () const |
| Returns the data src "exported" id. | |
| virtual Unit | unit () const |
| Returns the unit in which the data is expressed. | |
| virtual QString | description () const |
| Returns the data src description, when available. | |
| virtual int | size () const |
| Returns the dimension of the data src values, taking into account any applied transformations or dim filters. Equal to nlin() * ncol(). A size of zero means that this data src returns string values (valid only for attribute type). A value of -1 means that this object has not been fully initialised yet. | |
| virtual int | nlin () const |
| The number of lines in the returned result, taking into account any applied transformations or dim filters. A size of zero means that this data src returns string values (valid only for attribute type). A value of -1 means that this object has not been fully initialised yet. | |
| virtual int | ncol () const |
| The number of columns in the returned result, taking into account any applied transformations or dim filters. A size of zero means that this data src returns string values (valid only for attribute type). A value of -1 means that this object has not been fully initialised yet. | |
| virtual QString | formatStr () const |
| How should dataSrc values be formated? | |
| int | resultId () const |
| UnitConverter * | unitConverter () const |
 Public Member Functions inherited from GmResultDataSrcInfo | |
| virtual | ~GmResultDataSrcInfo () |
| Virtual destructor. | |
Private Member Functions | |
| Q_DISABLE_COPY (GmAttributeResultDataSrc) | |
Private Attributes | |
| int | _trackId |
| The numeric id for this data src (a value between 0 and the number of data srcs in the model) | |
| GmResultDataSrcType | _type |
| The data src type (needed while _info is NULL) | |
| QString | _alias |
| The data src alias (needed while _info is NULL) | |
| Unit | _unit |
| The exported unit. Might be different from _info->unit() | |
| const GmAttributeResultDataSrcInfo * | _info |
| The metadata info. Might be NULL for a while. | |
| int | _id |
| The attribute id inside GmResultData when _info is not NULL. -1 when it is. | |
| UnitConverter * | _conv |
| The unit converter, if necessary, from _info->unit() to _unit. | |
A class implementing the GmResultDataSrcInfo interface, storing the metadata and id for a result data registered attribute. It also stores the requested unit and the converter when needed. It is built with the result rule definition only (name + unit) and later completed with the data src definition (info + id)
