A set storing what should be exported (saved / printed / monitored) by the result rule classes. More...

#include <gmResultsDataSet.h>

Inheritance diagram for GmResultsDataSet:

Collaboration diagram for GmResultsDataSet:

[legend]

Public Member Functions
virtual	~GmResultsDataSet ()
	Destructor.

QString	id () const
	Returns the data set name.

int	monitorTrackId () const
	Returns the data set monitor track id if this data set is associated with a monitor rule, -1 otherwise.

void	setMonitorTrackId (int id)
	Updates the data set's monitor track id.

QString	description () const
	Returns the data set description.

GmMesh *	mesh () const
	Returns the mesh that contains the associated data. Can be NULL.

GmValueAccessor *	meshCoordAc () const
	Returns the node coordinate accessor associated with the data mesh or NULL for attribute only data sets.

int	numDataSrcs (int type=-1) const
	Returns the number of datasrcs in this data set if type is -1 or the number of data srcs of a specific type if type is a GmResultsDataSrcType enum value.

int	dataSrcIndex (GmResultsDataSrcType type, int i) const
	Returns the data src index of the ith data src of the given type.

const GmResultsDataSrcInfo *	dataSrcInfo (int index) const
	Returns the data src metadata given its index (between 0 and numDataSrcs())

int	dataSrcSize (int index) const
	Returns the number of result lines that exist for a data src, given its index.

const double *	dataSrcValue (int index, int line, QString &err) const
	Returns the line'th result associated with the data src identified by its index. As with any GeMA accessor, the returned buffer is valid only until the next call to dataSrcValue().

QString	strDataSrcValue (int index, int line, QString &err) const
	Returns the line'th string result associated with the data src identified by its index.

QString	explain (int index, int line) const
	Explains the evaluation point associated with the line'th result associated with the data src identified by its index. Results are a string like "node 5" or "cell 4 @ ip 2")

void	setDataSrcMonitorTrackId (int index, int id)
	Updates the data src monitor track id given its index (between 0 and numDataSrcs()) and new id.

GmResultsEvalSet *	evalSet (GmResultsDataSrcType type) const
	Returns the eval set associated with the given type.

void	print (const GmLogCategory &logger, GmLogLevel level) const
	Prints the data set description to the appointed logger / level.

Public Member Functions inherited from QObject
virtual const QMetaObject *	metaObject () const const

	QObject (QObject *parent)

virtual bool	event (QEvent *e)

virtual bool	eventFilter (QObject watched, QEvent event)

QString	objectName () const const

void	setObjectName (const QString &name)

bool	isWidgetType () const const

bool	isWindowType () const const

bool	signalsBlocked () const const

bool	blockSignals (bool block)

QThread *	thread () const const

void	moveToThread (QThread *targetThread)

int	startTimer (int interval, Qt::TimerType timerType)

int	startTimer (std::chrono::milliseconds time, Qt::TimerType timerType)

void	killTimer (int id)

T	findChild (const QString &name, Qt::FindChildOptions options) const const

QList< T >	findChildren (const QString &name, Qt::FindChildOptions options) const const

QList< T >	findChildren (const QRegExp &regExp, Qt::FindChildOptions options) const const

QList< T >	findChildren (const QRegularExpression &re, Qt::FindChildOptions options) const const

const QObjectList &	children () const const

void	setParent (QObject *parent)

void	installEventFilter (QObject *filterObj)

void	removeEventFilter (QObject *obj)

QMetaObject::Connection	connect (const QObject sender, const char signal, const char *method, Qt::ConnectionType type) const const

bool	disconnect (const char signal, const QObject receiver, const char *method) const const

bool	disconnect (const QObject receiver, const char method) const const

void	dumpObjectTree ()

void	dumpObjectInfo ()

void	dumpObjectTree () const const

void	dumpObjectInfo () const const

bool	setProperty (const char *name, const QVariant &value)

QVariant	property (const char *name) const const

QList< QByteArray >	dynamicPropertyNames () const const

void	destroyed (QObject *obj)

void	objectNameChanged (const QString &objectName)

QObject *	parent () const const

bool	inherits (const char *className) const const

void	deleteLater ()

	Q_DISABLE_COPY (Class)

	Q_DISABLE_MOVE (Class)

	Q_DISABLE_COPY_MOVE (Class)

T	qobject_cast (QObject *object)

T	qobject_cast (const QObject *object)

T	qFindChild (const QObject *obj, const QString &name)

QList< T >	qFindChildren (const QObject *obj, const QString &name)

QList< T >	qFindChildren (const QObject *obj, const QRegExp &regExp)

	Q_CLASSINFO (Name, Value)

	Q_INTERFACES (...)

	Q_PROPERTY (...)

	Q_ENUMS (...)

	Q_FLAGS (...)

	Q_ENUM (...)

	Q_FLAG (...)

	Q_ENUM_NS (...)

	Q_FLAG_NS (...)

	Q_OBJECT Q_OBJECT

	Q_GADGET Q_GADGET

	Q_NAMESPACE Q_NAMESPACE

	Q_NAMESPACE_EXPORT (EXPORT_MACRO)

	Q_SIGNALS Q_SIGNALS

	Q_SIGNAL Q_SIGNAL

	Q_SLOTS Q_SLOTS

	Q_SLOT Q_SLOT

	Q_EMIT Q_EMIT

	Q_INVOKABLE Q_INVOKABLE

	Q_REVISION Q_REVISION

	Q_SET_OBJECT_NAME (Object)

	QT_NO_NARROWING_CONVERSIONS_IN_CONNECT QT_NO_NARROWING_CONVERSIONS_IN_CONNECT

Static Public Member Functions
static GmResultsDataSet *	loadFromTable (LuaTable &tab, GmSimulationData *data, const GmLogCategory &parseLogger, const GmLogCategory &dataLogger)
	Parses a result data set definition from the given Lua table, returning a results data set object.

static GmNodeAcResultsDataSrc *	createNodeDataSrc (const GmMesh mesh, const QVariant &v, bool interp, const GmLogCategory &dataLogger, bool unknown, QString &srcId, QString &err)
	Aux function to create a new node data src from a "nodeData" entry, which can be a string or a Lua table. On error, returns false and fills err.

static GmCellAcResultsDataSrc *	createCellDataSrc (const GmCellMesh mesh, const QVariant &v, bool interp, const GmLogCategory &dataLogger, bool unknown, QString &srcId, QString &err)
	Aux function to create a new cell data src from a "cellData" entry. See comments on GmResultsDataSet::createNodeDataSrc().

static GmGaussAcResultsDataSrc *	createGaussDataSrc (const GmElementMesh mesh, const QVariant &v, bool interp, const GmLogCategory &dataLogger, bool unknown, QString &srcId, QString &err)
	Aux function to create a new cell data src from a "gaussData" entry. See comments on GmResultsDataSet::createNodeDataSrc().

Static Public Member Functions inherited from QObject
QString	tr (const char sourceText, const char disambiguation, int n)

QString	trUtf8 (const char sourceText, const char disambiguation, int n)

QMetaObject::Connection	connect (const QObject sender, const char signal, const QObject receiver, const char method, Qt::ConnectionType type)

QMetaObject::Connection	connect (const QObject sender, const QMetaMethod &signal, const QObject receiver, const QMetaMethod &method, Qt::ConnectionType type)

QMetaObject::Connection	connect (const QObject sender, PointerToMemberFunction signal, const QObject receiver, PointerToMemberFunction method, Qt::ConnectionType type)

QMetaObject::Connection	connect (const QObject *sender, PointerToMemberFunction signal, Functor functor)

QMetaObject::Connection	connect (const QObject sender, PointerToMemberFunction signal, const QObject context, Functor functor, Qt::ConnectionType type)

bool	disconnect (const QObject sender, const char signal, const QObject receiver, const char method)

bool	disconnect (const QObject sender, const QMetaMethod &signal, const QObject receiver, const QMetaMethod &method)

bool	disconnect (const QMetaObject::Connection &connection)

bool	disconnect (const QObject sender, PointerToMemberFunction signal, const QObject receiver, PointerToMemberFunction method)

Protected Member Functions
	GmResultsDataSet (QString id, QString description, GmAttributeResultsManager *attrManager)
	Constructor.

Protected Member Functions inherited from QObject
QObject *	sender () const const

int	senderSignalIndex () const const

int	receivers (const char *signal) const const

bool	isSignalConnected (const QMetaMethod &signal) const const

virtual void	timerEvent (QTimerEvent *event)

virtual void	childEvent (QChildEvent *event)

virtual void	customEvent (QEvent *event)

virtual void	connectNotify (const QMetaMethod &signal)

virtual void	disconnectNotify (const QMetaMethod &signal)

Private Slots
void	dataSrcInfoChanged (int size)
	A slot attached to the infoChanged() signal emited by a GmAttributeResultsDataSrc object when its info metadata field was changed due to an attribute being finally registered / unregistered at the orchestration.

Private Member Functions
	Q_DISABLE_COPY (GmResultsDataSet)

bool	addNodeDataSrc (const GmMesh *mesh, const QVariant &v, const GmLogCategory &dataLogger, QString &err)
	Aux function to add a new node data src to the set from its "nodeData" entry, which can be a string or a Lua table. On error, returns false and fills err.

bool	addCellDataSrc (const GmCellMesh *mesh, const QVariant &v, const GmLogCategory &dataLogger, QString &err)
	Aux function to add a new cell data src to the set from its "cellData" entry, which can be a string or a Lua table. On error, returns false and fills err.

bool	addGaussDataSrc (const GmElementMesh *mesh, const QVariant &v, const GmLogCategory &dataLogger, QString &err)
	Aux function to add a new Gauss data src to the set from its "gaussData" entry, which can be a string or a Lua table. On error, returns false and fills err.

bool	checkForMultipleAffectedNodes (GmAffectedNodes *affNodes) const
	Checks that the configured node data srcs have the same affected nodes property. Returns true if the set is multiple, false if not. Either way, fills affNodes with the "union" of the data sources affected nodes.

bool	checkForMultipleGaussRuleSets (int *ruleSet) const
	Checks that the configured gauss data srcs have the same integration rule set. Returns true if the set is multiple, false if not. When the set is not multiple, fills ruleSet with the common rule number.

bool	createNodeInterpolators (bool *needNatural, const GmLogCategory &logger, QString &err)
	Creates interpolators for transfering data from node attributes to cell points (for cell meshes) or to arbitrary points (for node meshes). Fills needNatural with true if any of the node data interpolators needs natural coordinates. Returns true on success or false on error (filling errr with a message).

bool	createGaussInterpolators (bool *needNatural, const GmLogCategory &logger, QString &err)
	Creates interpolators for transfering data from Gauss attributes to cell points (centroid or user given). Fills needNatural with true if any of the Gauss data interpolators needs natural coordinates. Returns true on success or false on error (filling errr with a message).

bool	allocResultBuffers ()
	Allocate space for the result buffers used to store interpolated results and/or returned results from translation functions.

const double *	nodeDataSrcValue (GmNodeAcResultsDataSrc *ds, int line, QString &err) const
	Returns the line'th result associated with the given node data src.

const double *	cellDataSrcValue (GmCellAcResultsDataSrc *ds, int line, QString &err) const
	Returns the line'th result associated with the given cell data src.

const double *	gaussDataSrcValue (GmGaussAcResultsDataSrc *ds, int line, QString &err) const
	Returns the line'th result associated with the given Gauss data src.

Static Private Member Functions
template<class T , class AcF >
static T *	createDataSrc (const QVariant &v, const AcF &acGet, bool interp, bool *unknown, QString &srcId, QString &err)
	Generic implementation for createXxxDataSrc functions. T is the data src type and AcF is the function used to return an accessor for the parsed id. It receives as parameters the id name, the requested history and unit. Keep in mind that the needed mesh and logger should already be known to acGet.

static bool	parseAndCheckDataSrcFields (GmAcResultsDataSrcBase ds, const GmValueInfo info, const QVariant &v, QString &err)
	Parse additional common DataSrc values: format, resultDim and transform. Also checks the basic information stored in the data src against the src metadata.

Private Attributes
QString	_id
	The data set id (name)

int	_monitorTrackId
	The monitor track id if this data set is associated with a monitor rule, -1 otherwise.

QString	_description
	A description of the data set.

GmAttributeResultsManager *	_attrm
	The attribute manager object used to provide values for result attributes.

GmMesh *	_mesh
	The mesh that this data set is tied to (can be NULL for attribute rules)

GmDiscontinuitySet *	_discSet
	The discontinuitySet that this data set uses for interpolation.

GmValueAccessor *	_coordAc
	The accessor used for accessing node coordinates.

QVector< GmResultsDataSrcInfo * >	_dataSrcs

int	_dataSrcPos [GM_RR_DS_NUMTYPES+1]
	A vector storing the position in _dataSrcs of the first entry of each type, with the last entry storing the number of data srcs. That means that the first entry is always 0 and for each type t, _dataSrcPos[t] gives the index while _dataSrcPos[t+1] - _dataSrcPos[t] gives the number of entries of type t in _dataSrcs.

GmResultsEvalSet *	_nodeEvalSet
	The evaluation set for node data sources.

GmResultsEvalSet *	_cellEvalSet
	The evaluation set for cell data sources.

GmResultsEvalSet *	_gaussEvalSet
	The evaluation set for gauss data sources.

double *	_resultBuffer
	The buffer used by xxxDataSrcValue() functions for returning interpolated data. Its size is the biggest data src accessor dimension size.

double *	_transformBuffer
	The buffer used to store the result from a "non ac" data src or user transformation function. Its size is the biggest data src size.

int	_transformBufferSize
	The size of _transformBuffer.

Additional Inherited Members
Public Types inherited from QObject
typedef	QObjectList

Properties inherited from QObject
	objectName

Detailed Description

A set storing what should be exported (saved / printed / monitored) by the result rule classes.

Data at Eval at Interpolation Natural coord

Nodes Node No - Cell centroid Yes Interpolator Cell Gauss point Yes Interpolator

User point Yes Interpolator

Cells Cell centroid No Mesh type Cell Gauss point No Mesh type

User point No Mesh type

Gauss points Cell centroid Yes Interpolator Cell Gauss point No Yes

User point Yes Interpolator

TODO: If, for a data src class, all the source interpolators are the same, we could use a single interpolator and do all line calculations in a single operation, which is much faster than multiple single interpolations (weights are the same for every data src)

TODO: Use NC2P interpolators (needs some extra configuration parameters)

Member Function Documentation

◆ addCellDataSrc()

bool GmResultsDataSet::addCellDataSrc	(	const GmCellMesh *	mesh,
		const QVariant &	v,
		const GmLogCategory &	dataLogger,
		QString &	err )

private

Aux function to add a new cell data src to the set from its "cellData" entry, which can be a string or a Lua table. On error, returns false and fills err.

If there exists both a cell attribute and a porperty with the same name, preference is given to cell attributes.

The given logger is used for accessor creation only. It should not be used for error messages.

◆ addGaussDataSrc()

bool GmResultsDataSet::addGaussDataSrc	(	const GmElementMesh *	mesh,
		const QVariant &	v,
		const GmLogCategory &	dataLogger,
		QString &	err )

private

Aux function to add a new Gauss data src to the set from its "gaussData" entry, which can be a string or a Lua table. On error, returns false and fills err.

The given logger is used for accessor creation only. It should not be used for error messages.

◆ addNodeDataSrc()

bool GmResultsDataSet::addNodeDataSrc	(	const GmMesh *	mesh,
		const QVariant &	v,
		const GmLogCategory &	dataLogger,
		QString &	err )

private

Aux function to add a new node data src to the set from its "nodeData" entry, which can be a string or a Lua table. On error, returns false and fills err.

The given logger is used for accessor creation only. It should not be used for error messages.

◆ allocResultBuffers()

bool GmResultsDataSet::allocResultBuffers ( )

private

Allocate space for the result buffers used to store interpolated results and/or returned results from translation functions.

The buffer is alocated with a size big enough for the result value of any of the data sources.

◆ cellDataSrcValue()

const double * GmResultsDataSet::cellDataSrcValue	(	GmCellAcResultsDataSrc *	ds,
		int	line,
		QString &	err ) const

private

Returns the line'th result associated with the given cell data src.

As with any GeMA accessor, the returned buffer is valid only until the next call to any xxxDataSrcValue() method. The dimension filter, if any, IS applied by this call. Returns NULL on errors. Should fill err for an anexpected error, such as an interpolation error, keeping it empty if the value can not be evaluated (is not defined) at the given line.

◆ createCellDataSrc()

GmCellAcResultsDataSrc * GmResultsDataSet::createCellDataSrc	(	const GmCellMesh *	mesh,
		const QVariant &	v,
		bool	interp,
		const GmLogCategory &	dataLogger,
		bool *	unknown,
		QString &	srcId,
		QString &	err )

static

Aux function to create a new cell data src from a "cellData" entry. See comments on GmResultsDataSet::createNodeDataSrc().

If there exists both a cell attribute and a porperty with the same name, preference is given to cell attributes.

◆ createGaussInterpolators()

bool GmResultsDataSet::createGaussInterpolators	(	bool *	needNatural,
		const GmLogCategory &	logger,
		QString &	err )

private

Creates interpolators for transfering data from Gauss attributes to cell points (centroid or user given). Fills needNatural with true if any of the Gauss data interpolators needs natural coordinates. Returns true on success or false on error (filling errr with a message).

Interpolators created by this function are stored in the data src objects.

◆ createNodeDataSrc()

GmNodeAcResultsDataSrc * GmResultsDataSet::createNodeDataSrc	(	const GmMesh *	mesh,
		const QVariant &	v,
		bool	interp,
		const GmLogCategory &	dataLogger,
		bool *	unknown,
		QString &	srcId,
		QString &	err )

static

Aux function to create a new node data src from a "nodeData" entry, which can be a string or a Lua table. On error, returns false and fills err.

In case of errors, fills err and returns NULL. The given logger is used for accessor creation only. It is not used for error messages. The srcId parameter will be filled with the requested id, as much as possible, even on errors. If different from NULL, unknown will be filled with true if there was an error getting an accessor for the requested id. Otherwise it will be filled with false.

The interp parameter controls wheter interpolation definition information will be read from v or not (this is used by GmFileIO routines that do not need interpolation methods).

◆ createNodeInterpolators()

bool GmResultsDataSet::createNodeInterpolators	(	bool *	needNatural,
		const GmLogCategory &	logger,
		QString &	err )

private

Creates interpolators for transfering data from node attributes to cell points (for cell meshes) or to arbitrary points (for node meshes). Fills needNatural with true if any of the node data interpolators needs natural coordinates. Returns true on success or false on error (filling errr with a message).

Interpolators created by this function are stored in the data src objects.

◆ dataSrcValue()

const double * GmResultsDataSet::dataSrcValue	(	int	index,
		int	line,
		QString &	err ) const

Returns the line'th result associated with the data src identified by its index. As with any GeMA accessor, the returned buffer is valid only until the next call to dataSrcValue().

Returns NULL, filling err on errors (an error on a user transformation function, for example). Returns NULL, keeping err empty if the value can not be evaluated at the given line.

◆ gaussDataSrcValue()

const double * GmResultsDataSet::gaussDataSrcValue	(	GmGaussAcResultsDataSrc *	ds,
		int	line,
		QString &	err ) const

private

Returns the line'th result associated with the given Gauss data src.

As with any GeMA accessor, the returned buffer is valid only until the next call to any xxxDataSrcValue() method. The dimension filter, if any, IS applied by this call. Returns NULL on errors. Should fill err for an anexpected error, such as an interpolation error, keeping it empty if the value can not be evaluated (is not defined) at the given line.

◆ loadFromTable()

GmResultsDataSet * GmResultsDataSet::loadFromTable	(	LuaTable &	tab,
		GmSimulationData *	data,
		const GmLogCategory &	parseLogger,
		const GmLogCategory &	dataLogger )

static

Parses a result data set definition from the given Lua table, returning a results data set object.

The first logger, parseLogger, is used to emmit messages during data set parsing. The second logger, dataLogger, is used by the data set to print data messages and so is also used to create the data accessors.

◆ nodeDataSrcValue()

const double * GmResultsDataSet::nodeDataSrcValue	(	GmNodeAcResultsDataSrc *	ds,
		int	line,
		QString &	err ) const

private

Returns the line'th result associated with the given node data src.

As with any GeMA accessor, the returned buffer is valid only until the next call to any xxxDataSrcValue() method. The dimension filter, if any, IS applied by this call. Returns NULL on errors. Should fill err for an anexpected error, such as an interpolation error, keeping it empty if the value can not be evaluated (is not defined) at the given line.

◆ strDataSrcValue()

QString GmResultsDataSet::strDataSrcValue	(	int	index,
		int	line,
		QString &	err ) const

Returns the line'th string result associated with the data src identified by its index.

Returns a NULL string (isNull() is true), filling err on errors. Returns a NULL string, keeping err empty, if the value can not be evaluated at the given line.

The documentation for this class was generated from the following files:

inc/results/gmResultsDataSet.h
src/results/gmResultsDataSet.cpp

Public Member Functions

Static Public Member Functions

Protected Member Functions

Private Slots

Private Member Functions

Static Private Member Functions

Private Attributes

Additional Inherited Members

Detailed Description

Data at Eval at Interpolation Natural coord

User point Yes Interpolator

User point No Mesh type

User point Yes Interpolator

Member Function Documentation

◆ addCellDataSrc()

◆ addGaussDataSrc()

◆ addNodeDataSrc()

◆ allocResultBuffers()

◆ cellDataSrcValue()

◆ createCellDataSrc()

◆ createGaussInterpolators()

◆ createNodeDataSrc()

◆ createNodeInterpolators()

◆ dataSrcValue()

◆ gaussDataSrcValue()

◆ loadFromTable()

◆ nodeDataSrcValue()

◆ strDataSrcValue()
